SQUARELINE™ Acoustical Metal Ceiling Tiles  E-mail this product to a friend

SQUARELINE™

Standard Acoustical Metal Ceiling Tiles Beveled Profile

• Expanded Metal
• Decorative - High Style
• Fiber Free
• Excellent sound absorption qualities
• Affordable and easily installed

MATERIAL: Expanded perforated metal with melamine foam backing.
PATTERN: Standard, Medium and Ultra
FEATURES: Expanded metal design.
APPLICATIONS: Offices, conference rooms, board rooms, airports, lobbies, convention centers, retail stores.
THICKNESS: .25" SIZES: 24"x24"
COLOR: White metal, chromed metal with colored backing inserts (light gray, charcoal gray and white).
FLAMMABILITY: Class 1 fire-rated for smoke density and flame spread.
INSTALLATION: Layin - 15/16” teebar grid system. Slight tegular edge.

Sound Absorption / Noise Reduction
Size	125Hz	250Hz	500Hz	1KHz	2KHz	4KHz	NRC
0.25” Thick	0.37	0.59	0.30	0.50	0.75	1.09	0.55
